Specification

Volts：12

Kilowatts (kw)：1.4

Overall Length (mm)：200

Mounting Hole (mm)：M10x1.25

Mount Hole Centres (mm)：110

Flange Diameter (mm)：74

Nose Cone Length (mm)：32

Pinion At Rest (mm)：20

Field Housing Diameter (mm)：72

Teeth：9TH

Rotation CW

Pinion Diameter (mm) 29

Note

Please Check With Pictures / Numbers / Specs Before Ordering.

Fitment

For Daihatsu

Delta V67 engine 3YC 2.0L Petrol 1984-1988

Delta V68 engine 3YC 2.0L Petrol 1984-1988

Rockey engine 3YE 2.0L Petol 1987-1989

Rockey engine 3YC 2.0L Petol 1984-1990

Rockey engine 3YC 2.0L Petol 1986-1989

For Great Wall

SA220 CC engine 491E 2.2L Petrol 2009-2014

For Toyota

4 Runner YN60R engine 3Y 2.0L Petrol 1984-1985

4 Runner YN63R engine 3Y 2.2L Petrol 1985-1988

4 Runner YN63R engine 4YE 2.2L Petrol 1988-1989

4 Runner YN130R engine 4YE 2.2L Petrol 1989-1990

Dyna YH 81R engine 2Y 1.8L Petrol 1985-1995

Dyna YY 50R engine 1Y 1.6L Petrol 1985-1987

Dyna YY 52R engine 3Y 2.0L Petrol 1985-1995

Dyna YY 61R engine 3Y 2.0L Petrol 1985-1995

Dyna YU 60R engine 3Y 2.0L Petrol 1984-1995

Dyna YU 62R engine 4Y 2.2L Petrol 1986-1991

Hiace YH50R engine 2YC 1.8L Petrol 1982-1986

Hiace YH51R engine 3Y 2.0L Petrol 1984-1989

Hiace YH52R engine 3Y 2.0L Petrol 1984-1989

Hiace YH61R engine 3Y 2.0L Petrol 1982-1989

Hiace YH62R engine 3Y 2.0L Petrol 1984-1989

Hiace YH63R engine 4Y 2.2L Petrol 1986-1990

Hiace YH71R engine 3Y 2.0L Petrol 1982-1989

Hiace YH80R engine 1YJ 1.6L Petrol 1985-1987

Hiace YH81R engine 2Y 1.8L Petrol 1987-1995

Hilux YN51R engine 2YJ 1.8L Petrol 1983-1988

Hilux YN55R engine 1YC 1.6L Petrol 1983-1987

Hilux YN56R engine 2YC 1.8L Petrol 1986-1991

Hilux YN57R engine 3Y 2.0L Petrol 1983-1987

Hilux YN60R engine 2YJ 2.0L Petrol 1983-1988

Hilux YN65R engine 3Y 2.0L Petrol 1983-1988

Hilux YN80R engine 2Y 1.8L Petrol 1988-1994

Hilux YN85R engine 2Y 1.8L Petrol 1988-1997

Hilux YN106R engine 4Y 2.2L Petrol 1988-1992

Hilux YN130R engine 3YE 2.0L Petrol 1989-1990

Lite-Ace YM20R engine 1YJ 1.6L Petrol 1982-1985

Lite-Ace YM21R engine 2YU 1.8L Petrol 1982-1985

Spacia YR22 engine 4Y-E 2.2L Petrol 1993-1998

Tarago YR21R engine 3YC 2.0L Petrol 1984-1990

Tarago YR22R engine 4YE 2.2L Petrol 1985-1990

Tarago YR31R engine 4YE 2.2L Petrol 1986-1990

Tarago YR43R engine 4YE 2.2L Petrol 1988-1989

Townace YM55R engine 2Y 1.8L Petrol 1986-1999

Townace YM60R engine 2Y 1.8L Petrol 1986-1999

Townace YR20R engine 2YU 1.8L Petrol 1982-1992

Townace YR21R engine 3YE 2.0L Petrol 1983-1996

Townace YR30R engine 3YE 2.0L Petrol 1985-1996

Package

1 x Starter Motor
