Features
Volts 12V
Kilowatts 1.4kw
Overall Length 188mm
Mount Hole Dia. 9mm
Mt. Hole Cnt. To Cnt. 104mm
Flange Dia. 74mm
Nose Cone Length 11mm
Pinion Dia. 29mm
Out of Mesh Clearance 19.7mm
Field Hsg. Dia. 72mm
Teeth 9TH
Rotation CW

Note

Please Check With Pictures / Numbers / Specs Before Ordering.

Fitment

Fit For Toyota HiAce RCH12R engine 2RZ-FE 2.4L Petrol 1995-2005
Fit For Toyota HiAce RCH41R engine 3RZ-FE 2.7L Petrol 1997-1999
Fit For Toyota HiAce RCH47R engine 3RZ-FE 2.7L Petrol 1997-1999
Fit For Toyota HiAce RZH101R engine 2RZ-FE 2.4L Petrol 1989-2002
Fit For Toyota HiAce RZH103R engine 2RZ 2.4L Petrol 1989-1998
Fit For Toyota HiAce RZH113R engine 2RZ 2.4L Petrol 1989-1998
Fit For Toyota HiAce RZH125R engine 2RZ 2.4L Petrol 1989-1998
Fit For Toyota HiAce RCH22R engine 2RZ-FE 2.4L Petrol 1999-2005
Fit For Toyota HiAce RCH103R engine 2RZ-E 2.4L Petrol 1998-2004
Fit For Toyota HiAce RCH113R engine 2RZ-E 2.4L Petrol 1998-2005
Fit For Toyota HiAce RCH125R engine 2RZ-E 2.4L Petrol 1998-2005
Fit For Toyota HiAce TRH200R engine 1TR-FE 2.0L Petrol 2004-On
Fit For Toyota HiAce TRH201R engine 2TR-FE 2.7L Petrol 2005-2015
Fit For Toyota HiAce TRH214R engine 2TR-FE 2.7L Petrol 2004-On
Fit For Toyota HiAce TRH219R engine 2TR-FE 2.7L Petrol 2004-On
Fit For Toyota HiAce TRH221R engine 2TR-FE 2.7L Petrol 2005-2015
Fit For Toyota HiAce TRH223R engine 2TR-FE 2.7L Petrol 2005-2015
Fit For Toyota HiAce TRH224R engine 2TR-FE 2.7L Petrol 2005-2015
Fit For Toyota HiLux RZN149R engine 3RZ-FE 2.7L Petrol 1998-2004
Fit For Toyota HiLux RZN154R engine 3RZ-FE 2.7L Petrol 1998-2005
Fit For Toyota HiLux TGN121R engine 2TR-FE 2.7L Petrol 2015-2020
Fit For Toyota HiLux TGN16R engine 2TR-FE 2.7L Petrol 2005-2015
Fit For Toyota Landcruiser RZJ95R engine 3RZ-FE 2.7L Petrol 1996-2002
Fit For Toyota Landcruiser RZJ120R engine 3RZ-FE 2.7L Petrol 2003-2004
Fit For Toyota Prado RZJ120R engine 3TR-FE 2.7L Petrol 2002-2004
Fit For Toyota Prado RZJ125R engine 3TR-FE 2.7L Petrol 2002-2004
Fit For Toyota Prado TRJ120R engine 2TR-FE 2.7L Petrol 2004-2009
Fit For Toyota Prado TRJ125R engine 2TR-FE 2.7L Petrol 2004-2009
Fit For Toyota Prado TRJ150R engine 2TR-FE 2.7L Petrol 2009-2019

Fit For Toyota Hiace KDH 2.7L Petrol

Package

1 x Starter Motor
