Specification

Volts：12V

Kw：0.7kw

Overall Length：262mm

Pinion At Rest：48mm

Housing Diameter：78mm

Teeth：10TH

Pinion Diameter：32mm

Note

Please Check With Pictures / Numbers / Specs Before Ordering.

Fitment

Fit For Mariner 50ELO 49.8ci 50 HP 1986-1987

Fit For Mariner 50ELPTO 49.8ci 50 HP 1986-1987

Fit For Mercury 60E 49.8ci 60 HP 1984

Fit For Mariner 60EL 49.8ci 60 HP1984-1985

Fit For Mariner 60ELO 49.8ci 60 HP 1986-1987

Fit For Mariner 60ELPT 49.8ci 60 HP 1984-1985

Fit For Mariner 60ELPTO 49.8ci 60 HP 1986-1987

Fit For Mercury 65HP 65 HP 1972-1974

Fit For Mercury 65HP 65 HP 1975-1976

Fit For Mercury 70E 49.8ci 70 HP 1978-1983

Fit For Mercury 70EL 49.8ci 70 HP 1978-1983

Fit For Mariner 70ELPT 49.8ci 70 HP 1980-1989

Fit For Mercury 70ELPTO 71.1ci 70 HP 1987-1989

Fit For Mercury 70HP 49.8ci 70 HP 1977

Fit For Mariner 75EL 66.6ci 75 HP 1984-1985

Fit For Mariner 75ELHPTO 71.1ci 75 HP 1989-1999

Fit For Mariner 75ELO 66.6ci 75 HP 1986

Fit For Mariner 75ELO 71.1ci 75 HP 1987-1991

Fit For Mariner 75ELPT 66.6ci 75 HP 1984-1986

Fit For Mariner 75ELPTO 71.1ci 75 HP 1987-1993

Fit For Mariner 75ELPTO 84.6ci 75 HP 1994-1999

Fit For Mercury 80E 66.6ci 80 HP 1978-1983

Fit For Mercury 80ELO 71.1ci 80 HP 1987-1989

Fit For Mariner 80ELPT 66.6ci 80 HP 1979-1983

Fit For Mercury 80ELPTO 71.1ci 80 HP 1987-1989

Fit For Mercury 85HP 85 HP 1976-1977

Fit For Mariner 90ELHPTO 71.1ci 90 HP 1991-1993

Fit For Mariner 90ELHPTO 84.6ci 90 HP 1994-1999

Fit For Mariner 90ELO 71.1ci 90 HP 1987-1988

Fit For Mariner 90ELPTO 71.1ci 90 HP 1987 -1993

Fit For Mariner 90ELPTO 84.6ci 90 HP 1994-1999

Fit For Mariner 90ELPTO Coastal 84.6ci 90 HP 1999

Fit For Mercury 90ELPTO Jet 65 84.6ci 90 HP 1994-1999

Cross Reference

API Marine：50-60315

API Marine：MOT3002

Arco Marine：5375

Barsanco：690-025

BBB Small Motor：22-5287

Cargo：110648

Dixie：MS-636

Dixie：206-04113

EMS：49-0011

Johnson Evinrude：4820140

Lester：5287

Lester：5708

Mallory：9-15002

Mercury Marine：50-57485

Mercury Marine：50-65436

Mercury Marine：50-66015

Mercury Marine：50-66015-2

Mercury Marine：50-88119

Mercury Marine：50-60315

Mercury Marine：50-66015T1

Mercury Marine：50-893891T

MES Motorcycle & Marine：S2063M

MES Motorcycle & Marine：S2063M-OE

Minnpar：57-2248

MP Parts：4-1140

Mpa Small Motor：P243N

Napa Small Motor：RN5708

PIC：160-135

Prestolite：MGD4108

Prestolite：MGD4108A

Prestolite：POC4003

RCP：ST-5708

Remy Small Motor：RS41006

Sierra Marine：18-5604

Sierra Marine：18-5606

Sierra Marine：18-5642

United Tech：0996440-M030SM

United Tech：4820140-M030SM

United Tech：4838640-M030SM

United Tech：SM01446

United Tech：SM09962

United Tech：SM09964

United Tech：SM48201

United Tech：SM48386

United Tech：SMH12C31

Wai：2-2076-UT

Wilson：71-06-5287

Wilson：91-06-1943

Wilson:91-09-1001

Wood Auto:STR1063

Package

1 x Starter Motor
