Installation Guide

Device Placement

Place The Device Behind The Pedals, Ensuring That The Flat Side Is Facing The Driver. The Open Slot Should Be Oriented Upwards.

Position Over Brake Pedal

Align The Slot Over The Brake Pedal Arm And Gently Press Down Until The Open Slot Sits On The Brake Pedal’S Rubber Pad. Ensure There Is A 60mm Overhang Of The Device Towards The Driver.

Adjust Position (If Necessary)

If You Encounter Resistance, Lift The Rear Of The Device By 20-30mm To Position It In The Deepest Part Of The Car’S Floor. Then, Gently Press The Front To Realign The Open Slot With The Brake Pedal.

Securing The Device

Install The Lock To Secure The Device In Place.

Carpet Placement

Ensure The Back Edge Of The Device Rests Directly On The Car’S Carpet, Not On A Floor Mat. If Using A Genuine Holden Floor Mat, The Device Should Be Positioned 20-30mm Above The Mat.

Force Application

Use Gentle Pressure Throughout The Installation Process To Avoid Damaging The Device Or The Vehicle. Excessive Force Is Not Required.

Fitment

Fit For Holden Commodore VF Automatic/Manual 2013-2017

Fit For Holden Statesman WN Automatic/Manual 2013-2017

Package

1 x Brake/Accelerator Pedal Security (Without Lock)
