Specifications

Clutch Diameter：146mm

Compressor Mounting：Direct Mount

Fitting Type：Vertical Pad

Pulley Section：B

Series：SD7H15

Suits Unit Make：For Sanden

Voltage：24

Oil Type：SP 10

Gauge Line：43.85mm

Oil Capacity：135ml

Dust Cover Y/N：No

Head Code：US Head

Weight：8kg

Refrigerant：R134a

Pulley Diameter：146mm



OEM Part Number

SD7H15, 8116



Fitment

Fit For Isuzu F Series FRR500 FTR900 FRR600 FTS800 FSR500 FRR500/550 FVM1400

Fit For Isuzu F Series FRR500, FTR900 7.8L 01/2003 -12/2007

Fit For F Series FRR600, FTS800 7.8L FVM1400 7.8L 11/2007

Fit For F Series FSR500 6.5L, FRR500/550 8.2L, FVM1400 9.8L 01/1988 - 12/2000



Package

1 x Air Con Compressor
