Volts    12
Amps    120
Adjusment Hole    M8x1.25
Pivot Hole (mm)    10
Adjustment To Pivot (mm)    168
Pivot Length (mm)    56
Inside Foot To Foot (mm)    NA
Pulley (mm)    64
No Of Grooves    1PV
Plug  RP261



Note

Please Check With Pictures / Numbers / Specs Before Ordering.



Fitment

Make Model Series Engine Years (mm/yy)

For HDT Brock VC 5.0L V8 Petrol - 308 cu.in Blue 01/1980 - 12/1981

For HDT Brock VH 4.2L V8 Petrol - 253 cu.in Blue 01/1982 - 12/1984

For HDT Brock VH 5.0L V8 Petrol - 308 cu.in Blue 01/1982 - 12/1984

For Holden Berlina VK 3.3L 6cyl Petrol - 202 cu.in Black 03/1984 - 02/1986

For Holden Berlina VK 3.3L 6cyl Petrol - 202 cu.in Red 03/1984 - 02/1986

For Holden Berlina VK 5.0L V8 Petrol - 308 cu.in Blue 03/1984 - 02/1986

For Holden Calais VK 3.3L 6cyl Petrol - 202 cu.in Red 03/1984 - 02/1986

For Holden Calais VK 5.0L V8 Petrol - 308 cu.in Blue 03/1984 - 02/1986

For Holden Camira JE 2.0L 4cyl Petrol - 20JD 04/1987 - 07/1989

For Holden Commodore VB 2.8L 6cyl Petrol - 173 cu.in Red 11/1978 - 03/1980

For Holden Commodore VB 3.3L 6cyl Petrol - 202 cu.in Red 11/1978 - 03/1980

For Holden Commodore VB 4.2L V8 Petrol - 253 cu.in Red 11/1978 - 03/1980

For Holden Commodore VB 5.0L V8 Petrol - 308 cu.in Red 11/1978 - 03/1980

For Holden Commodore VC 1.9L 4cyl Petrol - 1X Starfire 04/1980 - 09/1981

For Holden Commodore VC 2.8L 6cyl Petrol - 173 cu.in Blue 04/1980 - 09/1981

For Holden Commodore VC 3.3L 6cyl Petrol - 202 cu.in Blue 04/1980 - 09/1981

For Holden Commodore VC 4.2L V8 Petrol - 253 cu.in Blue 04/1980 - 09/1981

For Holden Commodore VC 5.0L V8 Petrol - 308 cu.in Blue 04/1980 - 09/1981

For Holden Commodore VH 1.9L 4cyl Petrol - 1X Starfire 10/1981 - 02/1984

For Holden Commodore VH 2.8L 6cyl Petrol - 173 cu.in Blue 10/1981 - 02/1984

For Holden Commodore VH 3.3L 6cyl Petrol - 202 cu.in Blue 10/1981 - 02/1984

For Holden Commodore VH 4.2L V8 Petrol - 253 cu.in Blue 10/1981 - 02/1984

For Holden Commodore VH 5.0L V8 Petrol - 308 cu.in Blue 10/1981 - 02/1984

For Holden Commodore VK 3.3L 6cyl Petrol - 202 cu.in Black 03/1984 - 02/1986

For Holden Commodore VK 3.3L 6cyl Petrol - 202 cu.in Red 03/1984 - 02/1986

For Holden Commodore VK 5.0L V8 Petrol - 304 cu.in Black 03/1984 - 02/1986

For Holden Commodore VK 5.0L V8 Petrol - 308 cu.in Blue 03/1984 - 02/1986

For Holden E-Series EH 2.4L 6cyl Petrol - 149 cu.in Red 08/1963 - 01/1965

For Holden E-Series EH 2.9L 6cyl Petrol - 179 cu.in Red 08/1963 - 01/1965

For Holden E-Series EJ 2.3L 6cyl Petrol - 138 cu.in Grey 07/1962 - 07/1963

For Holden E-Series EK 2.3L 6cyl Petrol - 138 cu.in Grey 05/1961 - 06/1962

For Holden F-Series FB 2.3L 6cyl Petrol - 138 cu.in Grey 01/1960 - 04/1961

For Holden F-Series FC 2.2L 6cyl Petrol - 132 cu.in Grey 05/1958 - 12/1959

For Holden F-Series FE 2.2L 6cyl Petrol - 132 cu.in Grey 07/1956 - 04/1958

For Holden F-Series FJ 2.2L 6cyl Petrol - 132 cu.in Grey 10/1953 - 06/1956

For Holden F-Series FX 2.2L 6cyl Petrol - 132 cu.in Grey 01/1948 - 09/1953

For Holden H-Series HD 2.4L 6cyl Petrol - 149 cu.in Red 02/1965 - 03/1966

For Holden H-Series HD 2.9L 6cyl Petrol - 179 cu.in Red 02/1965 - 03/1966

For Holden H-Series HG 2.6L 6cyl Petrol - 161 cu.in Red 07/1970 - 06/1971

For Holden H-Series HG 3.0L 6cyl Petrol - 186 cu.in Red 07/1970 - 06/1971

For Holden H-Series HG 4.2L V8 Petrol - 253 cu.in Red 07/1970 - 06/1971

For Holden H-Series HG 5.0L V8 Petrol - 308 cu.in Red 07/1970 - 06/1971

For Holden Monaro HG 3.0L 6cyl Petrol - 186 cu.in Red 07/1970 - 06/1971

For Holden Monaro HG 4.2L V8 Petrol - 253 cu.in Red 07/1970 - 06/1971

For Holden Monaro HG 5.0L V8 Petrol - 308 cu.in Red 07/1970 - 06/1971

For Holden H-Series HJ 2.8L 6cyl Petrol - 173 cu.in Red 10/1974 - 06/1976

For Holden H-Series HJ 3.3L 6cyl Petrol - 202 cu.in Red 10/1974 - 06/1976

For Holden H-Series HJ 4.2L V8 Petrol - 253 cu.in Red 10/1974 - 06/1976

For Holden H-Series HJ 5.0L V8 Petrol - 308 cu.in Red 10/1974 - 06/1976

For Holden Caprice HJ 5.0L V8 Petrol - 308 cu.in Red 10/1974 - 06/1976

For Holden Monaro HJ 3.3L 6cyl Petrol - 202 cu.in Red 10/1974 - 06/1976

For Holden Monaro HJ 4.2L V8 Petrol - 253 cu.in Red 10/1974 - 06/1976

For Holden Monaro HJ 5.0L V8 Petrol - 308 cu.in Red 10/1974 - 06/1976

For Holden Statesman HJ 5.0L V8 Petrol - 308 cu.in Red 10/1974 - 06/1976

For Holden H-Series HK 2.6L 6cyl Petrol - 161 cu.in Red 04/1968 - 04/1969

For Holden H-Series HK 3.0L 6cyl Petrol - 186 cu.in Red 04/1968 - 04/1969

For Holden H-Series HK 4.2L V8 Petrol - 253 cu.in Red 04/1968 - 04/1969

For Holden Monaro HK 2.6L 6cyl Petrol - 161 cu.in Red 04/1968 - 04/1969

For Holden Monaro HK 3.0L 6cyl Petrol - 186 cu.in Red 04/1968 - 04/1969

For Holden H-Series HQ 2.8L 6cyl Petrol - 173 cu.in Red 07/1971 - 09/1974

For Holden H-Series HQ 3.3L 6cyl Petrol - 202 cu.in Red 07/1971 - 09/1974

For Holden H-Series HQ 4.2L V8 Petrol - 253 cu.in Red 07/1971 - 09/1974

For Holden H-Series HQ 5.0L V8 Petrol - 308 cu.in Red 07/1971 - 09/1974

For Holden Monaro HQ 2.8L 6cyl Petrol - 173 cu.in Red 07/1971 - 09/1974

For Holden Monaro HQ 3.3L 6cyl Petrol - 202 cu.in Red 07/1971 - 09/1974

For Holden Monaro HQ 4.2L V8 Petrol - 253 cu.in Red 07/1971 - 09/1974

For Holden Monaro HQ 5.0L V8 Petrol - 308 cu.in Red 07/1971 - 09/1974

For Holden Statesman HQ 3.3L 6cyl Petrol - 202 cu.in Red 07/1971 - 09/1974

For Holden Statesman HQ 4.2L V8 Petrol - 253 cu.in Red 07/1971 - 09/1974

For Holden Statesman HQ 5.0L V8 Petrol - 308 cu.in Red 07/1971 - 09/1974

For Holden H-Series HR 2.6L 6cyl Petrol - 161 cu.in Red 04/1966 - 03/1968

For Holden H-Series HR 3.0L 6cyl Petrol - 186 cu.in Red 04/1966 - 03/1968

For Holden H-Series HT 2.6L 6cyl Petrol - 161 cu.in Red 05/1969 - 06/1970

For Holden H-Series HT 3.0L 6cyl Petrol - 186 cu.in Red 05/1969 - 06/1970

For Holden H-Series HT 4.2L V8 Petrol - 253 cu.in Red 05/1969 - 06/1970

For Holden H-Series HT 5.0L V8 Petrol - 308 cu.in Red 05/1969 - 06/1970

For Holden Monaro HT 3.0L 6cyl Petrol - 186 cu.in Red 05/1969 - 06/1970

For Holden Monaro HT 4.2L V8 Petrol - 253 cu.in Red 05/1969 - 06/1970

For Holden Monaro HT 5.0L V8 Petrol - 308 cu.in Red 05/1969 - 06/1970

For Holden H-Series HX 3.3L 6cyl Petrol - 202 cu.in Red 07/1976 - 09/1977

For Holden H-Series HX 4.2L V8 Petrol - 253 cu.in Red 07/1976 - 09/1977

For Holden H-Series HX 5.0L V8 Petrol - 308 cu.in Red 07/1976 - 09/1977

For Holden Caprice HX 5.0L V8 Petrol - 308 cu.in Red 07/1976 - 09/1977

For Holden Monaro HX 4.2L V8 Petrol - 253 cu.in Red 07/1976 - 09/1977

For Holden Monaro HX 5.0L V8 Petrol - 308 cu.in Red 07/1976 - 09/1977

For Holden Statesman HX 5.0L V8 Petrol - 308 cu.in Red 07/1976 - 09/1977

For Holden H-Series HZ 3.3L 6cyl Petrol - 202 cu.in Red 10/1977 - 03/1980

For Holden H-Series HZ 3.3L 6cyl Petrol - 202 cu.in Red 10/1977 - 08/1980

For Holden H-Series HZ 4.2L V8 Petrol - 253 cu.in Red 10/1977 - 03/1980

For Holden H-Series HZ 5.0L V8 Petrol - 308 cu.in Red 10/1977 - 03/1980

For Holden Caprice HZ 5.0L V8 Petrol - 308 cu.in Red 10/1977 - 03/1980

For Holden Monaro HZ 4.2L V8 Petrol - 253 cu.in Red 10/1977 - 03/1980

For Holden Monaro HZ 5.0L V8 Petrol - 308 cu.in Red 10/1977 - 03/1980

For Holden Statesman HZ 5.0L V8 Petrol - 308 cu.in Red 10/1977 - 03/1980

For Holden Utility WB 3.3L 6cyl Petrol - 202 cu.in Blue 04/1980 - 12/1985

For Holden Utility WB 4.2L V8 Petrol - 253 cu.in Blue 04/1980 - 12/1985

For Holden Utility WB 5.0L V8 Petrol - 308 cu.in Blue 04/1980 - 12/1985

For Holden Caprice WB 5.0L V8 Petrol - 308 cu.in Blue 04/1980 - 12/1985

For Holden Statesman WB 5.0L V8 Petrol - 308 cu.in Blue 04/1980 - 12/1985

For Holden Sunbird LX 1.9L 4cyl Petrol - Opel 03/1976 - 02/1978

For Holden Sunbird UC 1.9L 4cyl Petrol - 1X Starfire 03/1978 - 12/1980

For Holden Torana LC 2.3L 6cyl Petrol - 138 cu.in Red 11/1969 - 12/1971

For Holden Torana LC 2.6L 6cyl Petrol - 161 cu.in Red 11/1969 - 12/1971

For Holden Torana LC 2.8L 6cyl Petrol - 173 cu.in Red 11/1969 - 12/1971

For Holden Torana LH 2.8L 6cyl Petrol - 173 cu.in Red 03/1974 - 02/1976

For Holden Torana LH 3.3L 6cyl Petrol - 202 cu.in Red 03/1974 - 02/1976

For Holden Torana LH 4.2L V8 Petrol - 253 cu.in Red 03/1974 - 02/1976

For Holden Torana LH 5.0L V8 Petrol - 308 cu.in Red 03/1974 - 02/1976

For Holden Torana LJ 2.3L 6cyl Petrol - 138 cu.in Red 01/1972 - 02/1974

For Holden Torana LJ 2.8L 6cyl Petrol - 173 cu.in Red 01/1972 - 02/1974

For Holden Torana LJ 3.3L 6cyl Petrol - 202 cu.in Red 01/1972 - 02/1974

For Holden Torana LX 2.8L 6cyl Petrol - 173 cu.in Red 03/1976 - 02/1978

For Holden Torana LX 3.3L 6cyl Petrol - 202 cu.in Red 03/1976 - 02/1978

For Holden Torana LX 4.2L V8 Petrol - 253 cu.in Red 03/1976 - 02/1978

For Holden Torana LX 5.0L V8 Petrol - 308 cu.in Red 03/1976 - 02/1978

For Holden Torana UC 2.8L 6cyl Petrol - 173 cu.in Red 03/1978 - 12/1980

For Holden Torana UC 3.3L 6cyl Petrol - 202 cu.in Red 03/1978 - 12/1980

For Toyota Corona XT130 1.9L 4cyl Petrol - 1X Starfire 08/1979 - 04/1983



Package
1 x Alternator
