Specification

Volts：12

Amps：100

Adjustment Hole (mm)：Mx1.25

Pivot Hole (mm)：11xM10x1.25

Adjustment to Pivot (mm)：170

Pivot Length (mm)：/

Inside Feet To Feet (mm)：67

Pulley (mm)：63

No Of Grooves：6PV

Plug：RP224



Reference Part Number

27060-0V110, 27060-36010, 104210-1960, 104210-2270, 104210-2340

27060-0V010 27060-0V040 27060-0V090 27060-0V100 27060-0V110 27060-36010 27060-36011 27060-36060 27060-36061 27060-36070 27060-36071 270600V010 270600V040 270600V090 270600V100 270600V110 2706036010 2706036011 2706036060 2706036061 2706036070 2706036071 104210-1673 104210-1690 104210-2270 104210-2340 104210-2341 104210-2706 104210-8432 1042101673 1042101690 1042102270 1042102340 1042102341 1042102706 1042108432 A0282A0149 HXB-081 27060-0V070 27060-36020 270600V070 2706036020 104210-2550 104210-2610 104210-2550 1042102610 11408



Fitment

Fit For Toyota Camry ASV50R engine 2AR-FE 2.5L Petrol 2011-2017

Fit For Toyota RAV4 ASA44R engine 2AR-FE 2.5L Petrol 2013-2019



Package

1 x Alternator
